co-ax 同軸閥MK 10 DR-閥門-產品型號-北京漢達森機械技術有限公司

品牌co-ax	有效期至長期有效	最后更新2020-09-02 16:37
瀏覽次數11

co-ax 同軸閥MK 10 DR

吳亞男
QQ：2853369884

手機：17718583804
電話：010-64714988-212
傳真：010-64714988-668
郵件：tk2@handelsen.cn

吳亞男郵箱：tk2@handelsen.cn電話：010-64714988-212

co-ax 同軸閥MK 10 DR

標稱電壓 Un 24 V DC

Un 230 V 40-60 Hz AC

驅動 DC 直流電磁鐵

AC 內置式整流器的直流電磁鐵

絕緣等級 H 180 °C

防護等級 IP65

負載率 ED 100%

連接按DIN EN175301-803標準的插頭, 形式A 4個位置X90°, 電線直徑 6-8 mm

M12x1 按DESINA標準的接頭 / VDMA

閥門的設計是基于介質和工況的要求.這些因素可能導致設計、密封材料和特性與通用參數表上的規格有所不同.

特性

端口螺紋 G 1/4 - G 3/4

功能 NC

壓力范圍 0-40 / 0-100 bar

KV值 0 - 40 bar: 2,2 m3/h

0 - 100 bar:1,4 m3/h

介質氣態? 液態? 高污染?

流向見壓力范圍

開關周期 200 1/min

開關時間打開 135 ms

關閉 20 ms

介質溫度 DC -10 °C — +80 °C

AC -10 °C — +80 °C

環境溫度 DC -10 °C — +80 °C

AC -10 °C — +80 °C

重量 2,5 kg

coax電磁閥

coax氣動閥

coax壓力控制閥

coax插裝閥

coax真空閥

主要型號

coax同軸閥MK10

coax同軸閥MK15/FK15

coax同軸閥MK20/FK20

coax同軸閥MK25/FK25

coax同軸閥MK32/FK32

co-ax MK10

co-ax MK15

co-ax MK20

co-ax MK25

co-ax MK32

co-ax MK40

co-ax MK50

co-ax FK15

co-ax FK20

co-ax FK25

co-ax FK32

co-ax FK40

co-ax FK50

co-ax FK65

co-ax FK80

co-ax MK10DR

co-ax MK15DR

co-ax MK20DR

co-ax MK25DR

co-ax MK32DR

co-ax MK40DR

co-ax MK50DR

co-ax FK15DR

co-ax FK20DR

co-ax FK25DR

co-ax FK32DR

co-ax FK40DR

co-ax FK50DR

co-ax FK65DR

co-ax FK80DR

co-ax CFM08

co-ax MCF08

co-ax VMK10

co-ax VMK15

co-ax VMK20

co-ax VMK25

co-ax VMK32

co-ax VMK40

co-ax VMK50

co-ax VFK15

co-ax VFK20

co-ax VFK25

co-ax VFK32

co-ax VFK40

co-ax VFK50

co-ax VMK10DR

co-ax VMK15DR

co-ax VMK20DR

co-ax VMK25DR

co-ax VMK32DR

co-ax VMK40DR

co-ax VMK50DR

co-ax VFK15DR

co-ax VFK20DR

co-ax VFK25DR

co-ax VFK32DR

co-ax VFK40DR

co-ax VFK50DR

co-ax VSV-M40

co-ax VSV-M50

co-ax VSV-F40

co-ax VSV-F50

co-ax VSV-F65

co-ax VSV-F80

co-ax VSV-F100

co-ax VSV-F125

co-ax VSV-F150

co-ax VSV-F200

co-ax VSV-F250

co-ax VSV-M40DR

co-ax VSV-M50DR

co-ax VSV-F40DR

co-ax VSV-F50DR

co-ax VSV-F65DR

co-ax VSV-F80DR

co-ax VSV-F100DR

co-ax VSV-F125DR

co-ax VSV-F150DR

co-ax FCF-K65

co-ax FCF-K80

co-ax FCF-K100

co-ax FCF-K125

co-ax FCF65

磁性液壓缸ISO 6020/2

符合ISO 6020/2標準的拉桿液壓缸，用于電磁開關。

適用于標準中定義的所有安裝件，根據應用的條件和要求的性能，可以采用幾種密封配置。

ISO 6020/2-DIN 24554，帶拉桿。

產品特點

氣缸

ISO

6020/2 -DIN 24554 孔

從25到125

壓力

最大：160bar

感應器

里德

PNP

選件

ROD

不銹鋼

淬硬鋼

Nikrom組合

板

Conforti CD_SX_25_12_X_V_*_SJ 50_S___

Conforti CD_SX_25_18_A_Z_*_SJ 100_L_SF_SV_SR

Conforti CD_SX_32_14_B_K_*_SJ 150_H_ST_SZ_SH

Conforti CD_SX_32_18_E__*_SJ 200_G_SL_SK_

Conforti CD_SX_32_22_D__*_____

Conforti CD_SX_40_18_C__*_____

Conforti CD_SX_40_22_M__*_____

Conforti CD_SX_40_28_G__*_____

Conforti CD_SX_50_22_H__*_____

Conforti CD_SX_50_28_L__*_____

Conforti CD_SX_50_36_Q__*_____

Conforti CD_SX_63_28_R__*_____

Conforti CD_SX_63_36_S__*_____

Conforti CD_SX_63_45_T__*_____

Conforti CD_SX_80_36___*_____

Conforti CD_SX_80_45___*_____

Conforti CD_SX_80_56___*_____

Conforti CD_SX_100_45___*_____

Conforti CD_SX_100_56___*_____

Conforti CD_SX_100_70___*_____

Conforti CD_SX_125_56___*_____

Conforti CD_SX_125_70___*_____

Conforti CD_SX_125_90___*_____

Conforti CD_SX_160_70___*_____

Conforti CD_SX_160_90___*_____

Conforti CD_SX_160_110___*_____

Conforti CD_SX_200_90___*_____

Conforti CD_SX__110___*_____

Conforti CD_SX__140___*_____

北京漢達森德國本土采購，拼箱發貨報關，德國技術，終身售后服務，貨期保證，價格公道，歡迎垂詢!如需更多信息歡迎垂詢漢達森品牌專員吳亞男。

co-ax 同軸閥MK 10 DR

co-ax 同軸閥MK 10 DR

co-ax 同軸閥MK 10 DR
