德國CO-AX同軸閥 FK 20
| 武志鵬 QQ：2850590584 手機：17718588643 電話：010-64714988-214 傳真：010-64714988668 郵件：tk3@handelsen.cn |
 |
德國CO-AX公司成立于1960年，以生產同軸閥著稱，憑借豐富的經驗，可靠而經過嚴格測試的材質，過硬的質量管理，CO-AX的閥廣泛適用于真空、氣態、液態、膠狀、磨粒、污染性以及侵蝕性等各種介質。與常規閥相比，同軸閥能夠以高流量來控制高壓介質，有兩位兩通和三位兩通可選，連接方式允許螺紋連接和法蘭連接，可通過直動式螺線管和外部直接控制
COAX電磁閥、COAX電動調節閥、COAX氣動調節閥、COAX自力式調節閥、COAX溫度調節閥、COAX壓力調節閥、COAX電動球閥、COAX氣動球閥、COAX電動蝶閥、COAX氣動蝶閥及真空泵
FK系列
介質 氣態 液態 高粘稠 凝膠狀 高污染
流向 見壓力范圍
開關周期 20 1/min
開關時間 打開 600 ms
關閉 800 ms
介質溫度 DC -20 °C — +80 °C
AC -20 °C — +80 °C
環境溫度 DC -20 °C — +80 °C
AC -20 °C — +80 °C
重量 48,8 kg
標稱電壓 Un 24 V DC
Un 230 V 40-60 Hz AC
驅動 DC 直流電磁鐵
AC 內置式整流器的直流電磁鐵
絕緣等級 H 180 °C
防護等級 IP65
負載率 ED 100%
連接 按DIN EN175301-803標準的插頭, 形式A 4個位置X90°, 電線直徑 6-8 mm
閥門的設計是基于介質和工況的要求.這些因素可能導致設計、密封材料和特性與通用參數表上的規格有所不同.
